RSM-100A/CC Push To Talk Ptt Lapel Shoulder Microphone Walkie Talkie Remote Speaker Microphone For Two Way Radio

RSM-100A push to talk ptt lapel shoulder microphone walkie talkie remote speaker microphone for two way radio;with a 360° swivel clothing clip. Ideal for light-duty applications such as retail stores, commercial businesses, hotels and resorts.

Get A Quote
RSM-100A/CC Push To Talk Ptt Lapel Shoulder Microphone Walkie Talkie Remote Speaker Microphone For Two Way Radio

Details of RSM Radio-100A/CC Push To Talk Ptt Lapel Shoulder Microphone Two Way Microphone

Details of RSM-100A/CC Push To Talk Ptt Lapel Shoulder Microphone Walkie Talkie Remote Speaker Microphone For Two Way Radio
Details of RSM-100A/CC Push To Talk Ptt Lapel Shoulder Microphone Walkie Talkie Remote Speaker Microphone For Two Way Radio
Details of RSM-100A/CC Push To Talk Ptt Lapel Shoulder Microphone Walkie Talkie Remote Speaker Microphone For Two Way Radio

Specification of RSM-100A/CC Push To Talk Ptt Lapel Shoulder Microphone Walkie Talkie Remote Speaker Microphone For Two-Way Radio


Microphone Specification:

Sensitivity Range

-45± 3dB RL=1.0K Q Vs=2.0V(DC) 1KHz

Impedance Max

2.2K2 1kHz (RL=2.2KΩ)

Frequency

20-20KHz

Current Consumption Max

VS=2.0V RL=2.2KΩ MAX: 500 μA

Operation Voltage Range

2.5-10V (DC

Max Sound pressure Level

110dB S.P.L



Speaker Specification:

Impedance

8 Ω+15%@1KHZ

Sensitivity

89dB+10%/1Watt 0.5Meter

Resonance freq

(FO) 680HZ+20%

Frequency respond

F-5KHZ

Rated input power

1.0W

Maximum input power

1.5W



Diagram of RSM Radio-100A/CC To Talk Ptt Lapel Shoulder Microphone Two Way Microphone

Specification of RSM-100A/CC Push To Talk Ptt Lapel Shoulder Microphone Walkie Talkie Remote Speaker Microphone For Two-Way Radio
