RHS-0219A is a Lightweight Single Muff Style Headset with Inline PTT for two way radios. It has adjustable boom mic with foam wind sock. provides a comfortable way to communicate with your two way radio.
The headset provides High output Speaker and a boom microphone extends from the headset and will swivel up or down.
Microphone Specification: | |
Sensitivity Range | -54± 3dB RL=1.0K Q Vs=2.0V(DC) 1KHz |
Impedance Max | 2.2K2 1kHz (RL=2.2KΩ) |
Frequency | 20-20KHz |
Current Consumption Max | VS=2.0V RL=2.2KΩ MAX: 500 μA |
Operation Voltage Range | 2.5-10V (DC |
Max Sound pressure Level | 110dB S.P.L |
Speaker Specification: | |
Impedance | 100Ω+15%@1KHZ |
Sensitivity | 114dB+10%/1Watt 0.5Meter |
Resonance freq | (FO) 680HZ+20% |
Frequency respond | F-5KHZ |
Rated input power | 1.0W |
Maximum input power | 1.5W |
The RayTalk light weight headset provides solutions to ensure communication remains available and protects your hearing while operating in the noisy environment.
